• Dimensions
  (unfolded, excl. propellers)

• 470×585×215 mm (L×W×H)

• Dimensions (folded)

• 365×215×195 mm (L×W×H)

• Diagonal Wheelbase

• 668 mm

• Weight (incl. two batteries)

• 3770 ± 10 g

• Max Takeoff Weight

• 3998 g

• Operation Frequency^[1]

• 2.4000-2.4835 GHz; 5.725-5.850 GHz

Transmitter Power (EIRP)

• 2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)
  5.8 GHz: <33 dBm (FCC/SRRC); <14 dBm (CE)

Hovering Accuracy
(windless or breezy)

• Vertical: ±0.1 m (Vision System enabled); ±0.5 m (N-mode with GPS); ±0.1 m (RTK)
  Horizontal: ±0.3 m (Vision System enabled); ±1.5 m (N-mode with GPS); ±0.1 m (RTK)

RTK Positioning Accuracy
(fixed RTK enabled)

• 1 cm+1 ppm (horizontal)
  1.5 cm+1 ppm (vertical)

Max Angular Velocity

• Pitch: 150°/sec.; Yaw: 100°/sec.

Max Tilt Angle

• 35° (N-mode and Forward Vision System enabled: 25°)

Max Ascent/Descent Speed

• 6 m/s, 5 m/s

Max Tilt Descent Speed

• 7 m/s

Max Horizontal Speed

• 23 m/s

Max Service Ceiling Above Sea Level (without other payload)

• 5,000 m (with 1671 propellers)
  7,000 m (with 1676 propellers)

Max Wind Resistance

• 15 m/s
  12 m/s during taking off and landing

Max Hover Time ^[2]

• 36 min

Max Flight Time^[2]

• 41 min

Motor Model

• 3511

Propeller Model

• 1671
  1676 High Altitude (not included)

Ingress Protection Rating^[3]

• IP55

GNSS

• GPS+Galileo+BeiDou+GLONASS
  (GLONASS is supported only when RTK module is enabled)

• Operating Temperature

• -20° to 50° C (-4° to 122° F)

• Angular Vibration Range

• ±0.01°

• Controllable Range

• Pan: ±90°
  Tilt: -120° to +45°

• Mechanical Range

• Pan: ±105°
  Tilt: -135° to +60°
  Roll: ±45°

• Sensor

• 1/2″ CMOS, Effective pixels: 48M

• Lens

• Focal length: 21-75 mm (equivalent: 113-405 mm)
  Aperture: f/2.8-f/4.2
  Focus: 5 m to ∞

• Exposure Compensation

• ±3 ev (using 1/3 ev as step length)

• Electronic Shutter Speed

• Auto Mode:
  Photo: 1/8000-1/2 s
  Video: 1/8000-1/30 s
  M Mode:
  Photo: 1/8000-8 s
  Video: 1/8000 -1/30 s

• ISO Range

• 100-25600

• Max. Video Resolution

• 3840×2160

• Max Photo Size

• 8000×6000

• Sensor

• 1/2″ CMOS, Effective pixels: 12M

• Lens

• DFOV: 84°
  Focal length: 4.5 mm (equivalent: 24 mm)
  Aperture: f/2.8
  Focus: 1 m to ∞

• Exposure Compensation

• ±3 ev (using 1/3 ev as step length)

• Electronic Shutter Speed

• Auto Mode:
  Video:
  1/8000-1/2 s
  Video: 1/8000-1/30 sM Mode:
  Photo: 1/8000-8 s
  Photo: 1/8000-1/30 s

• ISO Range

• 100-25600

• Max. Video Resolution

• 3840×2160

• Photo Size

• 4000×3000

• Thermal Imager

• Uncooled VOx Microbolometer

• Lens

• DFOV: 61°
  Focal length: 9.1 mm (equivalent: 40 mm)
  Aperture: f/1.0
  Focus: 5 m to ∞

• Infrared Temperature Measurement Accuracy^[4]

• ±2°C or ±2% (using the larger value)

• Video Resolution

• Infrared Image Super-resolution Mode: 1280×1024
  Normal Mode: 640×512

• Photo Size

• Infrared Image Super-resolution Mode: 1280×1024
  Normal Mode: 640×512

• Pixel Pitch

• 12 um

• Temperature Measurement Method

• Spot Meter, Area Measurement

• Temperature Measurement Range

• High Gain Mode: -20° to 150° C (-4° to 302° F)
  Low Gain Mode: 0° to 500° C (32° to 932° F)

• Temperature Alert

• Supported

• Palette

• White Hot/Black Hot/Tint/Iron Red/Hot
  Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2

• Resolution

• 1920×1080

• DFOV

• 161°

• Frame Rate

• 30 fps

• Wavelength

• 905 nm

• Max Laser Power

• 3.5 mW

• Single Pulse Width

• 6 ns

• Measurement Accuracy

• ± (0.2 m + D×0.15%)
  D is the distance to a vertical surface

• Measuring Range

• 3-1,200 m (0.5×12 m vertical surface with 20% reflectivity)

• Capacity

• 5880 mAh

• Voltage

• 26.1 V

• Battery Type

• Li-ion 6S

• Energy

• 131.6 Wh

• Net Weight

• Approx. 685 g

• Operating Temperature

• -20° to 50° C (-4° to 122° F)

• Storage Temperature

• 20° to 30° C (68° to 86° F)

• Charging Temperature

• -20° to 40° C (-4° to 104° F)
  (When the temperature is lower than 10° C (50° F), the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)

• Chemical System

• LiNiMnCoO2

• Screen

• 7.02 inch LCD touchscreen, with a resolution of 1920×1200 pixels, and high brightness of 1200 cd/m²

• Internal Battery

• Type: Li-ion (6500 mAh @ 7.2 V)
  Charge Type: Supports battery station or USB-C charger maximum rated power 65W (max voltage of 20V)
  Charge Time: 2 hours
  Chemical System: LiNiCoAIO2

• External Battery(WB37 Intelligent Battery)

• Capacity: 4920 mAh
  Voltage: 7.6 V
  Battery Type: Li-ion
  Energy: 37.39 Wh
  Chemical System: LiCoO2

• Operating Time^[5]

• Internal Battery: Approx. 3 hours 18 min
  Internal Battery + External Battery: Approx. 6 hours

• Ingress Protection Rating^[3]

• IP54

• GNSS

• GPS+Galileo+BeiDou

• Operating Temperature

• -20° to 50° C (-4° to 122° F)

• Dimensions

• 353×267×148 mm

• Net Weight

• 3.95 kg

• Compatible Battery Type

• TB30 Intelligent Flight Battery
  WB37 Intelligent Battery

• Input

• 100-240 VAC, 50/60 Hz

• Output

• TB30 Battery Port: 26.1 V, 8.9 A (supported up to two outputs simultaneously)
  WB37 Intelligent Battery: 8.7 V, 6 A

• Output Power

• 525 W

• USB-C port

• Max. output power of 65 W

• USB-A port

• Max. output power of 10 W (5 V, 2 A)

• Power Consumption (when not charging battery)

• < 8 W

• Output Power (when warming up battery)

• Approx. 30 W

• Operating Temperature

• -20° to 40° C (-4° to 104° F)

• Ingress Protection Rating^[3]

• IP55 (with the cover closed properly)

• Charging Time^[6]

• Approx. 30 min (charging two TB30 batteries from 20% to 90%)
  Approx. 50 min (charging two TB30 batteries from 0% to 100%)

• Protection Features

• Anti-Backflow Protection
  Short Circuit Protection
  Over Voltage Protection
  Over Current Protection
  Temperature Protection

1. What are the key features of the DJI M30 Drone Camera? The DJI M30 features include a versatile camera system with thermal, zoom, and wide-angle capabilities, advanced obstacle sensing and avoidance, IP55 weather resistance, and a compact, foldable design for easy portability. It’s designed for a variety of industrial and emergency response applications.
2. What type of camera sensors does the DJI M30 have? The M30 is equipped with a triple-camera system that includes a 48MP zoom camera with 5x to 16x optical zoom, a 12MP wide-angle camera, and a thermal imaging camera, providing comprehensive imaging capabilities for various missions and applications.
3. How long can the DJI M30 fly on a single charge? The DJI M30 can achieve a maximum flight time of approximately 41 minutes under ideal conditions, with variations depending on factors such as payload weight, flight speed, weather conditions, and battery health.
4. Is the DJI M30 Drone Camera waterproof? The M30 is not waterproof but features an IP55 rating, making it resistant to dust and capable of withstanding water jets from any direction. This allows it to operate in challenging weather conditions, including light to moderate rain.
5. Can the DJI M30 be used for search and rescue operations? Yes, the M30 is highly suited for search and rescue operations thanks to its thermal imaging capabilities, long flight time, and advanced obstacle sensing and avoidance. Its ability to provide real-time video feed to operators makes it invaluable for rapid response in various emergency situations.
6. Does the DJI M30 support autonomous flight? The M30 supports several autonomous flight modes, including waypoint navigation, orbit, and follow modes. These features, combined with its advanced obstacle avoidance system, allow for safer and more efficient operations across a range of applications.
7. How does the DJI M30 perform in windy conditions? The M30 is designed to perform reliably in windy conditions and can withstand wind speeds up to 15 m/s (33 mph), ensuring stable flight and high-quality imaging even in challenging weather.
8. What software is compatible with the DJI M30 for data analysis? The DJI M30 is compatible with DJI FlightHub2 and DJI Terra, among other software solutions offered by DJI. These platforms allow for real-time data transmission, advanced flight planning, data analysis, and 3D mapping capabilities.
9. How can I maintain the DJI M30 to ensure its longevity? Regular maintenance includes cleaning the drone and its sensors, checking for firmware updates, inspecting propellers for damage, and storing the batteries properly. DJI also recommends professional maintenance checks at authorized service centers for optimal performance and safety.
10. Are there any legal considerations to be aware of when operating the DJI M30? Yes, drone operation is subject to local laws and regulations, which may include restrictions on flying in certain areas, mandatory registration, and obtaining necessary certifications or licenses. Operators are responsible for understanding and complying with these regulations to ensure safe and legal drone usage.

The DJI Matrice M30 emerges as a pivotal innovation in the realm of aerial imaging, setting a new benchmark for drones in professional sectors. Available on xboom.in, this robust drone camera combines DJI’s renowned engineering with advanced capabilities, making it an indispensable asset for a wide array of industries including emergency response, infrastructure inspection, and environmental monitoring. The DJI Matrice M30 is not just a drone; it’s a comprehensive solution that ensures precision, efficiency, and reliability for professional missions.

Introduction to DJI Matrice M30

The DJI Matrice M30 stands at the forefront of aerial technology, offering unmatched performance and versatility. Designed to cater to the rigorous demands of professional use, this drone is equipped with state-of-the-art imaging and flight technologies, ensuring superior data collection and operational safety in a variety of environmental conditions.

Unparalleled Performance and Reliability

Choosing the DJI Matrice M30 means opting for a drone that delivers exceptional performance and reliability. Its advanced propulsion system and all-weather capability ensure that it can operate in challenging conditions, from strong winds to heavy rain, providing consistent results every time. The Matrice M30’s dual-vision and ToF sensors offer enhanced situational awareness, making it safer to fly in complex environments.

Advanced Imaging Capabilities

At the core of the DJI Matrice M30’s capabilities lies its sophisticated camera system. Equipped with a 48MP zoom camera, a 12MP wide camera, and a laser rangefinder, the M30 captures high-resolution images and videos, providing detailed aerial data for precise analysis. This makes it an ideal tool for applications such as search and rescue, where clarity and detail can make a significant difference in operational outcomes.

Seamless Integration and Workflow

Integrating the DJI Matrice M30 into your workflow is seamless, thanks to its compatibility with DJI’s ecosystem of software and accessories. The drone’s advanced data transmission system ensures quick and reliable data sharing, while its compatibility with DJI FlightHub2 allows for efficient mission planning and management. This streamlined workflow significantly enhances operational efficiency, enabling users to focus on mission objectives rather than logistics.

Designed for a Wide Range of Applications

The versatility of the DJI Matrice M30 makes it suitable for a broad spectrum of applications. From conducting detailed inspections of critical infrastructure to supporting emergency response teams in natural disaster scenarios, the M30 provides the aerial insights needed for informed decision-making. Its robust design and advanced imaging capabilities also make it an excellent choice for environmental monitoring, enabling researchers to study hard-to-reach areas with minimal environmental impact.

Why xboom.in is Your Ideal Source for DJI Matrice M30

Purchasing the DJI Matrice M30 from xboom.in ensures that you’re not just buying a drone; you’re investing in a solution backed by comprehensive support and expertise. xboom.in is committed to providing customers with genuine DJI products, expert advice, and after-sales support, making it the go-to destination for professionals seeking the best in aerial technology.

Elevating Industrial and Creative Projects

The DJI Matrice M30 is set to revolutionize various industries, offering new possibilities for creative and industrial projects. Its high-resolution imaging and reliable performance open up new horizons for filmmakers, photographers, and content creators, allowing for the capture of stunning aerial footage that was previously unattainable.

Future-Proofing Your Aerial Operations

Investing in the DJI Matrice M30 is an investment in the future of your aerial operations. As the demand for high-quality aerial data and operational efficiency continues to grow, the M30 stands ready to meet these challenges. Its combination of advanced imaging capabilities, robust performance, and seamless integration with DJI’s ecosystem ensures that it will remain a valuable asset for years to come.

Conclusion: Transform Your Operations with DJI Matrice M30

The DJI Matrice M30, available on xboom.in, represents a significant advancement in drone technology, offering professionals a powerful tool to enhance their aerial operations. With its unparalleled imaging capabilities, robust performance, and versatility, the M30 is designed to meet the complex demands of modern industries, transforming the way we capture and analyze aerial data.

Step into the future of professional drone operations with the DJI Matrice M30. Visit xboom.in today and discover how this remarkable drone can elevate your projects and operational capabilities to new heights.
