JIYI OBSTACLE RADAR SENSOR
Performance in Any Weather: Our Obstacle Avoidance Radar Module performs flawlessly in any weather. You can rely on this technology to keep your drone safe in every environment, including intense sunlight, hot weather, fog, dust, wind, and the pitch-blackness of night.
High Sensitivity: The module’s high sensitivity makes it possible for it to swiftly and correctly detect impediments, allowing it to make split-second judgements to keep your drone safe.
Long Detection Range: Our radar module provides early warning against obstacles due to its long detection range, enabling your drone to take appropriate action well in advance.
Signal Transmission that is Quick and Stable The radar module’s signal transmission is not only Quick but also Exceptionally Stable. By doing this, you may rest easy knowing that your drone will always have access to real-time information about its surroundings.
- High sensitivity
- Long detection distance
- Fast signal transmission
- Stable signal transmission
- All-weather work
- Strong environmental adaptability
GENERAL
- Modulation Mode: FMCW
- Center Frequency: 24.125GHz
- Ranging Range: 1 ~ 25m
PRODUCT DESCRIPTION
- Ranging Accuracy: 0. 1m
- Range Resolution: 0. 6m
- Output Frequency: 40Hz
- Power Waste: 3.0W @25°C
PRODUCT VOLTAGE
- Working Voltage: 9-28V
- Working Temperature: -20°C~+85°C
- Output Interface: CAN
