Autel 15KG DragonFish Pro with T3H
A high-end drone designed for aerial photography and cinematography on a professional level is the Autel 15KG DragonFish Pro with T3H. It can shoot breathtaking photographs and videos with ease with to its 15-kilogram payload capacity and cutting-edge T3H flight controller, which provides stability, precision, and intelligent flight modes. It is the ideal option for both tough activities and creative projects because it is reliable and durable.
Simple, clever, and effective.
The innovative tilt-rotor design of the Dragonfish makes operation simple while maximising performance and effectiveness. The Dragonfish is modular, waterproof, intelligent, and dependable because it has no complicated moving parts. The Dragonfish has a wide range of modular payload options, strong AI tracking capabilities, and is mission ready right out of the box. The Dragonfish’s strong mission capabilities are further strengthened by an endurance of up to 180 minutes (with payload), which puts it far ahead of the competitors.
Longevity with Payload
The Dragonfish Lite, Dragonfish Standard, and Dragonfish Pro are the three models that make up the Dragonfish line. Each model can significantly increase job efficiency with a flight time of 75 minutes, 120 minutes, and 180 minutes, respectively, while carrying a cargo.
Safety and Redundancy
DRAGONFISH FLIGHT LOGIC
Intelligence And Autonomy
Using the Dragonfish’s extensive selection of automated features, streamline mission tasks.
The Autel Dragonfish is capable of handling even the most challenging operations because to its sophisticated AI and flight control technology.
One-Click Takeoff/Landing
AI High-Speed Tracking
Point of Interest
Terrain Follow
RTK Accuracy
The two RTK (Real-Time Kinetic) modules on the Dragonfish allow the aircraft to deliver centimeter-accurate location data when coupled with a GNSS base station, allowing you to map with confidence. For added security, the dual units back up each other’s data. They also enhance the quality of image information and boost flight safety and precision.
System for Changing Payloads
With a range of payload options that can be quickly switched out to meet mission requirements, you can handle any activity. In order to maximize the system’s utility and improve its mission performance, Dragonfish payloads are made to be convertible across different aircraft classes.
9.7″ Autel Ground Control Station 1000nit
The 9.7-inch screen on the Autel Ground Control Station is easy to view in strong sunshine because to its ultra-bright touchscreen, which has 1,000 nits of brightness, which is twice as bright as the typical smartphone.
*When the base station is employed, the picture transmission distance is 18.6 miles. The picture transmission distance is 6.2 miles in the absence of a base station.
One Device. Any Mission.
The one-stop solution for every assignment, Autel Voyager is incredibly strong yet easy to use. The software offers sophisticated mission planning, intelligent tracking, flight history tracking, and other autonomous functions that are tailored exclusively for the Dragonfish.
• Offsite mission planning is possible for waypoint, polygonal, and rectangular missions, and it only takes one click to initiate autonomous flying after planning. At any point throughout the mission, the pilot can take over control to perform an emergency manoeuvre or construct a unique flight path.
• Tap to Fly: Choose a target on the camera, and the Dragonfish will fly there and orbit the object on its own.
• Mission management — assign flights and keep track of previous missions.
• Quick Mission: The Dragonfish will automatically depart from its original travel plan to pursue the needs of the pilot if points of interest are set on the flight map during any section of the mission.
Compact and portable
- The Dragonfish fits into the trunk of any typical-sized automobile and is simple to disassemble by one person. Without using any tools, the entire system can be put together and is ready to fly in less than five minutes.
- In 5 seconds, the entire system performs a self-check, and in 5 minutes, it is ready to fly.
- Assembly is made simple and practical by the blade’s quick-release construction.
Safety Mechanisms
Specifications
Ground Control Station
| Video Transmission | Operating frequency： 902-928 MHz； 2.4-2.4835 GHz Max Transmitting Distance (unobstructed, free of interference)： FCC：10 km CE / MIC：5 km SRRC：5 km |
| Data Transmission | Operating frequency： 5.725 – 5.755 GHz |
| Wi-Fi | Protocol： Wi-Fi Direct; Wireless; Display; 802.11a/g/n/ac; Wi-Fi with 2×2 MIMOOperating frequency： 2.400 – 2.4835 GHz 5.150 – 5.250GHz 5.650 – 5.755GHz 5.725 – 5.850 GHz |
| Battery | Type: Li-Po Capacity: 8200mAh Voltage:11.4 V Type：Li-Po Energy：93 Wh Charging time：120 min |
| Run Time | ~3 hrs (Max brightness) ~4.5 hrs (Half brightness) |
| Storage Capacity | ROM 256GB + scalable (TF) |
| Video Output Port | HDMI Port |
| Power Supply Current / Voltage (USB-A port) | 5V / 500mA |
| Operating Temperature Range | -20℃ ~ 40℃ |
| Charging Temperature Range | 0℃ ~ 45℃ |
| Storage Temperature Range | < 1 month: -4° to 140° F (-20° to 60° C) 1-3 months: -4° to 113° F (-20° to 45° C) 3-12 months: -4° to 86° F (-20° to 30° C) |
| GNSS | GPS+GLONASS+Galileo |
| Dimensions | 319×233×74 mm（antennas folded） 319×398×74 mm（antennas unfolded） |
| Weight | 1987g |
Base Station
| GNSS receiver | Satellite receiving frequency (Simultaneously receive): GPS：L1，L2，L5 BeiDou：B1，B2，B3 GLONASS：F1，F2 Galileo：E1，E5A，E5BPositioning accuracy： Single Point Horizontal: 1.5 m (RMS) Vertical: 3.0 m (RMS) RTK Horizontal: 1 cm+1 ppm (RMS) Vertical: 1.5 cm+ 1 ppm (RMS) 1 ppm: For every 1 km increase in distance, the accuracy will be 1 mm less. For example, the horizontal accuracy is 1.1 cm when the receiving end is 1 km away from the base station.Positioning update rate：1Hz，2 Hz，5 Hz，10 Hz and 20HzCold start：< 40s Hot start：< 10s Recapture：< 1s Initialization reliability：> 99.9% Differential data transmission format：RTCM 2.X/3.X |
| Communication | Data link：Image transmission, Wi-Fi |
| Image transmission | Operating frequency：2.4000-2.4835 GHz；902-928 MHz EIRP (Equivalent radiated power)： 902-928 MHz FCC：< 30 dBm 2.400-2.4835 GHz FCC：< 30 dBm SRRC/CE/MIC：< 20 dBm |
| Wi-Fi | Operating frequency：5.125-5.25GHz；5.650-5.755GHz；5.725-5.850GHz
EIRP (Equivalent radiated power) Communication distance： |
| Electrical characteristics | Power consumption：7.5 W Power supply：5 ~ 20V DC（supports USB PD charging protocol） Battery： Type: lithium ion polymer battery Capacity: 4950 mAh Energy: 57.1 WH |
| Physical properties | Size(Base station body + extension rod)：193 mm×177 mm×73 mm Weight：1275g Dustproof and waterproof：IP64 Operating temperature：-20℃ ~ 50℃ |
