Description
DJI Avata 2 (Drone Only)
4K/60fps HDR Videos: Unleash your true aerial potential. The 4K/60fps HDR on Avata 2 captures all the awesome of high-speed flight. In the goggles, you can adjust the sharpness and noise reduction levels for more finely tuned videos.
Rock Steady: Equipped with DJI’s latest stabilization algorithm, Avata 2 captures smooth, steady footage even when flying at high speeds or in windy conditions.
Horizon Steady: HorizonSteady handles horizontal rotations up to 360 Degree , ensuring the captured footage remains locked on the horizon even if the drone turns sharply or sways dramatically.
155 Degree Ultra-Wide-Angle FOV: Amplify your vision and increase the immersion of low-altitude, high-speed flights. Avata 2 offers ultra-wide-angle, wide-angle, and normal-angle FOV options giving you the ability to adjust to the scenario.
10-bit D-Log M: Capture rich detail in highlights and shadows and enhance content post-production opportunities while further streamlining color-grading.
Got You Covered – Comprehensive Safety: The updated integrated propeller guard design of Avata 2 makes it lighter and more agile, enabling it to navigate freely in tight spaces. Releasing the accelerator on RC Motion 3 or pressing the lock button brings the drone to a halt, allowing you to handle unexpected situations calmly. In addition, the automatic Return to Home (RTH) function is initiated when the drone’s battery is low or in case of signal loss, adding an extra layer of security.
Advanced Positioning with New Sensors: New binocular fisheye sensors enable downward and backward visual positioning during low-altitude and indoor flights, enhancing flight stability and safety.
Turtle Mode: Avata 2 can automatically flip itself back into takeoff position when upside down with Turtle mode enabled, so you can quickly get airborne again.
The Sky’s the Limit With Longer Flight: Avata 2 boasts a maximum flight time of 23 minutes and supports PD fast charging, so you can quickly recharge it and take to the skies again.
The new DJI Avata 2 Two-Way Charging Hub features a power accumulation function, allowing the transfer of remaining power from multiple batteries to the one with the highest charge level, giving you an “extra battery” in critical moments.
1/1.3-inch Image Sensor
Tight Shots in Super-Wide 4K
Experience the exhilaration of flying with stunning 4K/60fps HDR video. Delight in the expansive 155° ultra-wide-angle field of view, perfect for capturing dramatic low-altitude, high-speed flights. This technology offers a broader perspective, ensuring every dynamic detail is vividly captured, enhancing your visual experience as you soar through the skies.
Built-in Propeller Guard
Easy ACRO
Turtle Mode
Binocular Fisheye Visual Positioning
Specifications
Aircraft
- Takeoff Weight:
- Approx. 13.29 oz (377g)
- Max Ascent Speed:
- 6 m/s (Normal mode)
9 m/s (Sport mode) - Max Descent Speed:
- 6 m/s (Normal mode)
9 m/s (Sport mode) - Max Horizontal Speed:
- (Near sea level, no wind):
8 m/s (Normal mode)
16 m/s (Sport mode)
27 m/s (Manual mode) - Max Takeoff Altitude:
- 5000m
- Max Flight Time:
- Approx. 23 mins
- Max Hovering Time:
- Approx. 21 mins
- Max Flight Distance:
- 13.0 km
- Max Wind Speed Resistance:
- 10.7 m/s (Level 5)
- Operating Temperature:
- 14 Degree to 104 Degree F (-10 Degree to 40 Degree C)
- Global Navigation Satellite System:
- GPS + Galileo + BeiDou
- Hovering accuracy range:
- Vertical:
+/-0.1 m (with vision positioning)
+/-0.5 m (with GNSS positioning)Horizontal:
+/-0.3 m (with vision positioning)
+/-1.5 m (with GNSS positioning) - Internal Storage:
- 46GB
- Dimensions (L x W x H):
- 7.28 x 8.34 x 2.51″ (185 x 212 x 64mm)
Camera
- Image Sensor:
- 1/1.3″ image sensor
Effective Pixels: 12 MP - Lens:
- FOV: 155 Degree
Format Equivalent: 12 mm
Aperture: f/2.8
Focus: 0.6 m to Infinite - ISO Range:
- 100-25600 (Auto)
100-25600 (Manual) - Shutter Speed:
- Video: 1/8000-1/30 s
Photo: 1/8000-1/50 s - Max Image Size:
- 4000 x 2256 (16:9)
4000 x 3000 (4:3) - Still Photography Mode:
- Single shot
- Photo Format
- JPEG
- Video Resolution:
- 4K (4:3): 3840 x 2880@30/50/60fps
4K (16:9): 3840 x 2160@30/50/60fps
2.7K (4:3): 2688 x 2016@30/50/60fps
2.7K (16:9): 2688 x 1512@30/50/120fps
1080p (4:3): 1440 x 1080@30/50/120fps
1080p (16:9): 1920 x 1080@30/50/120fps - Video Format:
- MP4 (H.264/H.265)
- Max Video Bitrate:
- 130 Mbps
- Supported File System:
- exFAT
- Color Mode:
- Standard
D-Log M - Camera FOV:
- Supports normal mode, wide-angle mode, and ultra-wide-angle mode.
- EIS:
- Supports RockSteady 3.0+ and HorizonSteady
(Can be disabled)
Gimbal
- Stabilization:
- Single-axis mechanical gimbal (tilt)
- Mechanical Range:
- Tilt: -95 Degree to 90 Degree
- Controllable Range:
- Tilt: -85 Degree to 80 Degree
- Max Control Speed (tilt):
- 100 Degree /s
- Angular Vibration Range:
- +/-0.01 Degree
- Electronic Roll Axis:
- Real-time screen correction is unavailable during recording, but can be applied to the footage recorded on the drone.
Sensing
- Sensing Type:
- Downward and backward visual positioning
- Downward:
- ToF Effective Measurement Height: 10 m
Precise Hovering Range: 0.3-10 m
Measurement Range: 0.3-20 m
FOV: Horizontal 78 Degree , Vertical 78 Degree - Backward:
- Measurement Range: 0.5-20 m
FOV: Horizontal 78 Degree , Vertical 78 Degree - Operating Environment:
- Diffuse reflective surfaces with discernible patterns, diffuse reflectivity > 20% (such as concrete pavement)
Adequate lighting (lux > 15, normal indoor lighting conditions)
Video Transmission
- Video Transmission System:
- O4
- Live View Quality:
- 1080p@30/50/60/100fps
- Operating Frequency:
- 2.400-2.4835 GHz
5.170-5.250 GHz
5.725-5.850 GHz - Transmitter Power (EIRP):
- 2.4 GHz:
<33 dBm (FCC)
<20 dBm (CE/SRRC/MIC)5.1 GHz:
< 23 dBm (CE)5.8 GHz:
<33 dBm (FCC)
<30 dBm (SRRC)
< 14 dBm (CE) - Communication Bandwidth:
- Max 60 MHz
- Max Transmission Distance:
- (Unobstructed, free of interference)
:FCC: 13 km (subject to the aircraft’s max flight distance)
CE: 10 km
SRRC: 10 km
MIC: 10 km(Unobstructed, with interference):
Strong Interference: Urban landscape, approx. 1.5-4 km
Medium Interference: Suburban landscape, approx. 4-10 km
Low Interference: Suburb/seaside, approx. 10-13 km - Max Transmission Distance (Contd.):
- (Obstructed, with interference):
Low Interference and Obstructed by Buildings: approx. 0-0.5 km
Low Interference and Obstructed by Trees: approx. 0.5-3 km - Max Download Speed:
- Wi-Fi: 30 MB/s
- Lowest Latency:
- With DJI Goggles 3:
1080p/100fps Video Transmission Quality: 24 ms
1080p/60fps Video Transmission Quality: 40 ms - Max Video Bitrate:
- 60Mbps
- Antennas:
- 4 antennas, 2T4R
Wi-Fi
- Protocol:
- 802.11a/b/g/n/ac
- Operating Frequency:
- 2.400-2.4835 GHz
5.725-5.850 GHz - Transmitter Power (EIRP):
- 2.4 GHz:
<20 dBm (FCC/CE/SRRC/MIC)5.8 GHz:
<20 dBm (FCC/SRRC)
< 14 dBm (CE)
Bluetooth
- Protocol:
- Bluetooth 5.0
- Operating Frequency:
- 2.400-2.4835 GHz
- Transmitter Power (EIRP):
- <10 dBm
Charger
Recommended Charger:
- DJI 65W Portable Charger
DJI 65W Car Charger
USB Power Delivery charger
Storage
Recommended microSD Cards:
- SanDisk Extreme PRO 32GB U3 A1 V30 microSDHC
Lexar Professional 1066x 64GB U3 A2 V30 microSDXC
Lexar Professional 1066x 128GB U3 A2 V30 microSDXC
Lexar Professional 1066x 256GB U3 A2 V30 microSDXC
Lexar Professional 1066x 512GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 64GB U3 A2 V30 microSDXC - Recommended microSD Cards (Contd.):
- Kingston CANVAS Go! Plus 128GB U3 A2 V30 microSDXC
Kingston CANVAS React Plus 64GB U3 A1 V90 microSDXC
Kingston CANVAS React Plus 128GB U3 A1 V90 microSDXC
Kingston CANVAS React Plus 256GB U3 A1 V90 microSDXC
Samsung EVO Plus 512GB U3 A2 V30 microSDXC
Intelligent Flight Battery
Capacity:
- 2150 mAh
- Standard Voltage:
- 14.76 V
- Max Charging Voltage:
- 17 V
- Energy:
- 31.7 Wh@0.5C
- Charging Temperature:
- 41 Degree to 104 Degree F (5 Degree to 40 Degree C)
- Charging Time:
- With Charging Hub (60W max charging power):
From 0 to 100%: approx. 45 min
From 10 to 90%: approx. 30 minDirectly Charging the Drone (30 W max charging power):
From 0 to 100%: approx. 88 min
From 10 to 90%: approx. 60 min - Battery Info:
- Required, included
- Battery Material:
- Lithium ion
- Battery Type:
- Non-universal
- Battery Quantity:
- 1
- Weight:
- Approx. 5.11 oz (145g)
FAQs for DJI Avata 2 (Drone Only)
- What are the key features of the DJI Avata 2 drone?
The DJI Avata 2 features a compact design, integrated propeller guards, a 1/1.3-inch image sensor for 4K HDR video recording, 12MP stills, and supports one-button acrobatic maneuvers. - Does the DJI Avata 2 come with a controller?
The DJI Avata 2 (Drone Only) package does not include a controller. Compatible controllers are available for purchase separately. - Can the DJI Avata 2 be used for indoor flying?
Yes, the Avata 2 is equipped with binocular fisheye sensors that enable stable and safe indoor flying by enhancing visual positioning. - What is the flight time of the DJI Avata 2?
The Avata 2 can fly for approximately 18-20 minutes on a fully charged battery, depending on flight conditions and usage. - How fast can the DJI Avata 2 fly?
The DJI Avata 2 can reach speeds of up to 60 km/h (approximately 37 mph). - What type of battery does the DJI Avata 2 use?
The DJI Avata 2 uses a specific lithium-polymer battery designed for this model, which is available for purchase separately if you require additional batteries. - Is the camera on the DJI Avata 2 adjustable?
Yes, the Avata 2 features a gimbal that supports movements in multiple directions, allowing for flexible camera angles and smoother video capture. - Does the DJI Avata 2 support automatic takeoff and landing?
Yes, the Avata 2 includes features for automatic takeoff and landing, making it easier for all levels of pilots to operate the drone. - What is Turtle mode on the DJI Avata 2?
Turtle mode is a recovery feature that allows the DJI Avata 2 to flip itself back into an upright position if it lands upside down, enabling it to take off again. - Can the DJI Avata 2 capture footage in low light?
Thanks to its enhanced 1/1.3-inch sensor, the Avata 2 performs better in low-light conditions, ensuring quality footage during early morning or late evening flights.
