DJI Goggles N3

₹45,999

Experience flight from a pilot’s perspective.
Roomy design fits glasses for ultimate comfort.
1080p ultra-wide screen for immersive visuals.
Head tracking for effortless flight control.
2.7-hour battery life for extended creativity.

1 Year Warranty

After Sales Service

Description

Introducing The DJI Goggles N3

The DJI Goggles N3 offers an immersive and seamless flying experience, designed to bring you into the cockpit with advanced features like head tracking and a 1080p ultra-wide screen. When paired with DJI Neo, DJI Avata 2, and DJI RC Motion 3, these goggles enhance your control and provide smooth, high-definition video transmission. The design is comfortable, even for glasses wearers, and includes defogging capabilities for changing weather. Whether you’re a seasoned pilot or a newcomer, the DJI Goggles N3 makes every flight feel like a personal adventure.

Features

Feature	Details
Head Tracking	Control flight with head or wrist movements.
Roomy Design	Comfortable fit for glasses wearers.
Integrated Design	Combines headband and battery for balance.
One-Tap Defogging	Prevents fogging by accelerating air circulation.
1080p Ultra-Wide Screen	54° FOV for clear and immersive visuals.
O4 FHD Video Transmission	1080p/60fps live feed with minimal latency.
AR Cursor	Use DJI RC Motion 3 to control settings.
2.7-Hour Battery Life	Long operating time for extended flying.
Compatibility	Works with DJI Avata 2 and DJI Neo.
Max Video Transmission Range	Up to 13 km with stable connection.

In The Box

DJI Goggles N3 × 1

Compatibility

DJI Avata 2
DJI Neo

Effortlessly perform aerial acrobatics with Neo, as Goggles N3 plunges you into the excitement of 360° front/back flips, left/right rolls, and 180° drifts.

Click here to learn more about the DJI Neo

Activate Easy ACRO on Avata 2 with a single push using the DJI FPV Remote Controller series, and dive into thrilling action with DJI Goggles N3

Click here to learn more about the DJI Avata 2

Integrated Design

The headband and battery are combined into one design, balancing the overall weight to ensure a comfortable fit without pressure on your face.

One-Tap Defogging

When fog accumulates on the lenses, the defogging feature accelerates the internal fan to circulate air and eliminate moisture, ideal for varying temperatures and humid conditions.

Ready to Use with O4 FHD Video Transmission for Seamless Immersion

Spacious, Eyewear-Compatible Design

The generously roomy interior is thoughtfully designed to comfortably accommodate glasses, eliminating the need for diopter adjustments or lens installations. This thoughtful feature ensures that you can effortlessly wear your regular eyewear while enjoying an immersive flight experience. Simply put on the goggles, and you’re all set to take off and explore the skies without any hassle or added steps.

Minimal Latency, Reliable Video Transmission

The DJI O4 digital video transmission system features a 2T4R antenna design for superior anti-interference. Enjoy 1080p/100fps live feeds with only 31 ms latency and a range of up to 13 km. The goggles automatically choose the best frequency band (2.4 GHz to 5.8 GHz) based on your environment, ensuring stable and smooth real-time video. With a max bitrate of 60 Mbps and SyncSmooth technology, the video feed stays smooth even during high-speed flights.

Enhanced Viewing and Interaction Features

AR Cursor

The DJI RC Motion 3 [2] can function as an AR cursor before takeoff or while the aircraft is hovering after braking. This enables you to activate functions and adjust settings without needing to remove your hands from the RC Motion 3.

1080p Ultra-Wide Screen

The DJI Goggles N3 features a 1080p 60Hz LCD screen with a wide 54° FOV. Experience crisp visuals with minimal discomfort as dramatic aerial views unfold before you.

LCD Screen Specifications
Resolution: 1920 × 1080 | Refresh Rate: 60 Hz | Max Brightness: 1350 nits

Real-Time Live Feed Sharing

By connecting DJI Goggles N3 to your smartphone with a USB-C cable, you can display a secondary live feed via the DJI Fly app. This feature makes sharing and teaching easier by allowing others to view the live feed in real time.

Immersive Viewing and Extended Battery Life

Panorama Video Playback

Load panoramic videos onto a microSD card and enjoy immersive cinematic views through DJI Goggles N3. Experience stunning panoramic footage in your everyday life.

2.7-Hour Battery Life

With a fully charged DJI Goggles N3, you can use it for up to 2.7 hours, equivalent to the duration of 13 DJI Neo batteries. Maximize your creative potential with this long-lasting battery performance.

Specifications

Goggles

Category	Details
Model	TKGSM
Weight	– 536 g (battery and headband included) – 349 g (battery and headband excluded)
Dimensions	– Antennas folded: 193×163×103 mm (L×W×H) – Antennas unfolded: 206×163×132 mm (L×W×H)
Screen Size (single screen)	3.5 inches
Resolution (single screen)	1920×1080
Refresh Rate	Up to 60 Hz
Interpupillary Distance	No adjustment required; ready to use immediately
Diopter Adjustment	Not supported; compatible with personal glasses
Field of View (FOV)	54°
Video Recording Format	MOV (video format: H.264)
Supported Formats	– Video and Audio Playback: MP4, MOV – Video coding formats: H.264, H.265 – Audio formats: AAC, PCM – Panoramic Video: Spherical 2D panoramic videos
Max Video Specification	4K/60fps
Real View Display	Not supported
Operating Temperature	-10° to 40° C (14° to 104° F)
Power Input	Built-in battery
Supported SD Cards	microSD (up to 512 GB)
Recommended microSD Cards	– Lexar Professional 1066x: 64GB, 128GB, 256GB, 512GB U3 A2 V30 microSDXC – Kingston CANVAS Go! Plus: 64GB, 128GB, 256GB, 512GB U3 A2 V30 microSDXC

Video Transmission

Category	Details
Video Transmission	O4
Operating Frequency	– 2.400-2.4835 GHz – 5.150-5.250 GHz – 5.725-5.850 GHz
Notes on Frequency	Operating frequencies vary by country and region. Refer to local laws and regulations for details.
Transmitter Power (EIRP)	2.4 GHz: – < 30 dBm (FCC) – < 20 dBm (CE/SRRC/MIC)5.1 GHz: – < 23 dBm (CE) – < 21 dBm (FCC)5.8 GHz: – < 33 dBm (FCC) – < 30 dBm (SRRC) – < 14 dBm (CE)
Latency	With DJI Avata 2: – 1080p/100fps: Minimum 31 msWith DJI Neo: – 1080p/60fps: Minimum 58 msMeasured in open, outdoor environments without interference or obstructions.
Max Transmission Distance	With DJI Avata 2: – 13 km (FCC) – 10 km (CE/SRRC/MIC)With DJI Neo: – 10 km (FCC) – 6 km (CE/SRRC/MIC)Actual max distance is affected by the aircraft’s max flight distance and environment.
Max Video Bitrate	With DJI Avata 2: 60 Mbps With DJI Neo: 50 MbpsMeasured in open, outdoor environments without interference or obstructions.

GFSK

Category	Details
Operating Frequency	2.400-2.4835 GHz
Transmitter Power (EIRP)	– < 26 dBm (FCC) – < 20 dBm (CE/SRRC/MIC)

Battery

Category	Details
Dimensions	120×71×44 mm (L×W×H)
Capacity	2450 mAh
Voltage	6.33-8.4 V
Type	Li-ion
Chemical System	LiNiMnCoO2
Energy	17.28 Wh
Charging Temperature	5° to 45° C (41° to 113° F)
Max Charging Power	5 V/3 A (charging when powered off)
Runtime	2.7 hours
Note on Runtime	Measured at 25° C (77° F), screen brightness at 6, connected to DJI Avata 2, video transmission set to 1080p/100fps, Head Tracking off, and goggles’ battery fully charged with no external power usage.
