Description
DJI Transmission Combo
The DJI Transmission Combo is an advanced communication system designed specifically for drone enthusiasts and professional pilots. This innovative combo includes a high-quality transmission module that enhances the signal strength and stability between the drone and the remote controller, allowing for seamless and reliable control over long distances. With its cutting-edge technology, the DJI Transmission Combo ensures minimal latency and interference, providing a smooth and immersive flying experience. Whether you’re a recreational flyer or a professional aerial photographer, this combo enables you to push the boundaries of your drone’s capabilities and capture stunning footage with ease. It’s the perfect accessory for anyone seeking enhanced control and performance from their DJI drone.
Long-Distance HD Live Feed
O3 Pro video transmission technology offers an incredible 6km/20,000ft [1] transmission distance. It also supports transmission at 1080p/60fps.
Integrated Wireless Receiver
Integrating monitor and receiver with many expansion features.
End-to-End Ultra-Low Latency
Uses the same chip solution as Ronin 4D, with every link explicitly optimized to provide end-to-end ultra-low transmission latency.
Triple-Band Seamless Auto Hopping
Supports triple-band automatic frequency hopping between 2.4 GHz, 5.8 GHz, and DFS. It also automatically scans the electromagnetic environment for the optimal wireless channel.
Remote Gimbal/Focus/Camera Control
When used with devices like Ronin 4D Hand Grips or DJI Master Wheels, [2] you can remotely control Ronin 2, RS 3 Pro, focus, and camera functions.
End-to-End Ultra-Low Latency
The video transmitter and receiver use the same chip solution as Ronin 4D, with every link explicitly optimized to provide end-to-end ultra-low transmission latency when pairing with cinema cameras like ALEXA Mini LF.
Seamless Auto Frequency Hopping
O3 Pro adds DFS bands* on top of the traditional 2.4 GHz and 5.8 GHz frequency bands, offering up to 23 channel options that provide professional crews with more compliant and interference-free transmission channels. In addition, DJI Transmission supports triple-band automatic frequency hopping, which automatically scans the electromagnetic environment for the best wireless channel.
With a built-in frequency sweeper, users can even manually select the optimal channel to avoid interference between devices.
By mounting high-gain antennas, [2] transmission capability is further boosted.
Meanwhile, for crews operating with multiple members and teams, such as lighting, art department, and props, Broadcast mode can also be enabled to allow an unlimited number of receivers (transmission performance differs with Broadcast mode enabled). This brings shooting efficiency and awareness to an entirely new level.
One Transmitter with Multiple Receivers
The High-Bright Remote Monitor supports one transmitter with multiple receivers for video and audio feeds in two transmission modes. In Control mode, DJI Transmission delivers optimal transmission performance. Monitoring can be done from two receivers at the same time, while Ronin 2, RS 3 Pro, and camera focus can all be controlled remotely.
Specifications
Display
| Panel Type | Receiver: LCD |
| Display Size | 7.0″ / 17.8 cm |
| Display Size | Receiver: 7.0″ / 17.8 cm |
| Resolution | Receiver: 1920 x 1200 |
| Aspect Ratio | Receiver: 16:10 |
| Touchscreen | Yes |
| Image Controls | False Color, Focus Peaking, Screen Markers, Waveform, Zebra |
Inputs / Outputs
| Video I/O | Transmitter: 1 x HDMI 1.4 Input Transmitter: 1 x BNC (3G-SDI) Input Transmitter: 1 x BNC (3G-SDI) Loop Output Receiver: 1 x HDMI 2.0 Input Receiver: 1 x HDMI 1.4 Output Receiver: 1 x BNC (3G-SDI) Output |
| Embedded Audio | HDMI/SDI |
| Audio I/O | Receiver: 1 x 1/8″ / 3.5 mm Headphone Output |
| Power | Transmitter/Receiver: 1 x Barrel Input |
| Other I/O | Receiver: 1 x USB-C 2.0 Input |
| Media/Memory Card Slot | Single Slot: microSD/microSDHC |
| Encryption | 256-Bit AES |
Wireless
| Wireless Range | 3.7 Miles / 6 km (Line-of-Sight) |
| # of Channels | 23 |
| Channel Bandwidth | 40 MHz |
| Frequency Range | Non-DFS Frequencies 2.4 to 2.48 GHz 5.15 to 5.25 GHz 5.72 to 5.85 GHz DFS Frequencies 5.25 to 5.35 GHz 5.47 to 5.6 GHz 5.65 to 5.72 GHz |
| Latency | 68 ms |
| RF Power | < 33 dBm |
| Wi-Fi | Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz) |
| Bluetooth | None |
| Mobile App Compatible | No |
Format Support
| Video Format | HDMI/SDI (10-Bit 4:2:2 YCC) 1080p: 60/59.94/50/30/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 |
| Audio Format | 16-Bit 48 kHz PCM Audio |
| Wireless Video Compression | Compressed |
| Timecode Support | Yes |
Power
| DC Input Power | 6 to 18 VDC |
| Battery Type | Transmitter/Receiver: 1 x L-Series (Interchangeable Mount) |
| Power Consumption | Transmitter/Receiver: 11 W |
Environmental
| Environmental Protection | None |
| Certifications | CE, FCC *as per Manufacturer |
| Operating Temperature | 22 to 77°F / -10 to 45°C |
General
| Dimensions | Transmitter: 5 x 3.4 x 1″ / 127 x 87 x 26 mm Receiver: 8.4 x 5.3 x 2″ / 213 x 135 x 51 mm |
| Weight | Transmitter: 12.3 oz / 350 g, Excluding Antenna Receiver: 1.6 lb / 727 g, Excluding Antenna |
