DJI Agras T25

1 customer review

1,500,000

  • High-Precision Spraying System
  • Intelligent Flight Modes
  • Real-Time Kinematic (RTK) Positioning
  • Advanced Obstacle Avoidance
  • Robust and Durable Design
  • Comprehensive Management System
  • Versatile Application Scenarios

1-Year Warranty     7 days return policy     PAN India Fast Shipping

Description

DJI Agras T25 Agricultural Drone

The DJI Agras T25 is a cutting-edge agricultural drone designed to enhance farming efficiency. Equipped with advanced spraying and spreading systems, it ensures precise and uniform application of pesticides and fertilizers. Its robust construction and weather-resistant design make it ideal for various terrains and climates. With intelligent flight modes and real-time monitoring, the T25 maximizes productivity and reduces labor costs. Perfect for modern farming, the DJI Agras T25 brings innovation and reliability to your agricultural operations.

DJI Agras T25

The DJI Agras T25 is a state-of-the-art agricultural drone designed to revolutionize precision farming practices with its advanced features and robust capabilities. One of its standout features is the high-precision spraying system, which is equipped with sophisticated nozzles and a high-pressure pump. This system ensures uniform and precise liquid application, making it efficient for covering large areas quickly and effectively. Additionally, the drone offers intelligent flight modes, including automated flight planning and execution, terrain-following, and contour-following, allowing it to adapt seamlessly to various field conditions and provide streamlined operations.

DJI Agras T25

The Agras T25 boasts Real-Time Kinematic (RTK) positioning technology, enhancing GPS accuracy to centimeter-level precision. This ensures precise navigation and stable flight even in challenging environments. Coupled with advanced obstacle avoidance capabilities, the drone is equipped with multiple sensors that detect obstacles in all directions, providing reliable and safe operation in the field.

DJI Agras T25

Designed for durability, the Agras T25 features a robust and weather-resistant construction that can withstand harsh agricultural environments. Its components are easy to clean and maintain, ensuring long-term reliability. The drone’s large payload capacity allows it to carry substantial liquid loads for extended spraying sessions, and the quick-release tank system facilitates easy refilling, reducing downtime.

DJI Agras T25

Efficiency is a hallmark of the DJI Agras T25, which can cover up to 25 acres per hour, significantly boosting operational efficiency. Its high flight speed and optimized flight paths minimize working time, while the comprehensive management system, integrated with the DJI Agras Management Platform, allows for efficient planning, monitoring, and analysis of flight data. Real-time data transmission and cloud storage further enhance fleet management capabilities.

DJI Agras T25

User-friendliness is another key feature, with an intuitive remote controller that includes a bright, high-resolution display for easy operation. The accompanying user-friendly app provides detailed guidance and real-time feedback, making control seamless even for those new to drone technology. The modular design of the Agras T25 ensures that components can be easily assembled, disassembled, and maintained, allowing for quick repairs and upgrades to minimize downtime.

DJI Agras T25

The Agras T25 is versatile and can be used for various agricultural tasks, including spraying pesticides, herbicides, and fertilizers, making it suitable for different crop types and field sizes. Its high-capacity batteries provide extended flight durations, supported by an efficient power management system that maximizes battery life and flight time. To ensure safety, the drone includes emergency stop and return-to-home functions, along with redundant systems to enhance operational reliability.

DJI Agras T25

In summary, the DJI Agras T25 is a powerful and versatile agricultural drone that offers high efficiency, precision, and ease of use. Its advanced features, robust design, and comprehensive management system make it an invaluable tool for modern agriculture, significantly enhancing the efficiency and effectiveness of farming operations.

Specifications

Aircraft

  • Weight

  • 25.4 kg (excl. battery)
    32 kg (incl. battery)
  • Max Takeoff Weight[1]

  • Max takeoff weight for spraying: 52 kg (at sea level)
    Max takeoff weight for spreading: 58 kg (at sea level)
  • Max Diagonal Wheelbase

  • 1925 mm
  • Dimensions

  • 2585×2675×780 mm (arms and propellers unfolded)
    1475×1540×780 mm (arms unfolded and propellers folded)
    1050×690×820 mm (arms and propellers folded)
  • Hovering Accuracy Range (with strong GNSS signal)

  • RTK enabled:
    Horizontal: ±10 cm, Vertical: ±10 cm
    RTK disabled:
    Horizontal: ±60 cm, Vertical: ±30 cm (radar module enabled: ±10 cm)
  • RTK/GNSSOperating Frequency

  • RTK:
    GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galieo E1/E5b, QZSS L1/L2
    GNSS:
    GPS L1, BeiDou B1I, GLONASS F1, Galieo E1, QZSS L1
  • Max Configurable Flight Radius

  • 2000 m
  • Max Wind Resistance

  • 6 m/s

Propulsion System - Motors

  • Stator Size

  • 100×28 mm
  • KV

  • 59 rpm/V
  • Power

  • 4600 W/rotor

Propulsion System - Propellers

  • Material

  • Nylon carbon fiber filament
  • Dimension

  • 50 inch
  • Propeller Rotation Diameter

  • 1270 mm
  • Quantity

  • 4

Dual Atomizing Spraying System - Spray Tank

  • Material

  • Plastic (HDPE)
  • Volume

  • 20 L
  • Operating Payload [1]

  • 20 kg[1]
  • Quantity

  • 1

Dual Atomizing Spraying System - Sprinklers

  • Model

  • LX8060SZ
  • Quantity

  • 2
  • Nozzle Distance

  • 1368 mm(Rear Nozzles)
  • Droplet Size

  • 50-500 μm
  • Effective Spray Width[2]

  • 4-7 m (at a height of 3 m above the crops)

Dual Atomizing Spraying System - Delivery Pumps

  • Type

  • Impeller pump (magnetic drive)
  • Quantity

  • 2
  • Single Pump Flow Rate

  • 0-12 L/min
  • Max Flow Rate

  • 16 L/min (2 sprinklers)
    24 L/min (4 sprinklers)

DJI AGRAS T25 Spreading System

  • Compatible Material Diameter

  • 0.5-5 mm
  • Spread Tank Volume

  • 35 L
  • Spread Tank Internal Load [10]

  • 25 kg[1]
  • Effective Spraying Width

  • Varies according to material diameter, spinner disk rotational speed, hopper outlet size, and flight altitude. For optimal performance, it is recommended to adjust the corresponding variables to achieve a spreading range of 5-8 meters.

Phased Array Radar System

  • Model

  • RD241608RF (forward phased array radar)
    RD241608RB (rear phased array radar)
  • Terrain Follow

  • Max slope in mapping-free operation: 50°
    Altitude detection range: 1-50 m
    Stabilization working range: 1.5-30 m
  • Obstacle Avoidance[4]

  • Obstacle sensing range (multidirectional): 1-50 m

    FOV:
    Forward phased array radar: horizontal 360°, vertical ±45°, upward ±45° (cone)
    Rear phased array radar: vertical 360°, horizontal ±45°
    Working conditions: flying higher than 1.5 m over the obstacle at a horizontal speed no more than 10 m/s and vertical speed no more than 3 m/s.

    Safety limit distance: 2.5 m (distance between the front of propellers and the obstacle after braking)

    Sensing direction: 360° multidirectional sensing

FAQ's

  • What is the payload capacity of the DJI Agras T25?
    • The DJI Agras T25 can carry a substantial liquid load, enabling extended spraying sessions. Its large payload capacity helps cover more area in a single flight, enhancing operational efficiency.
  • How accurate is the DJI Agras T25 in terms of positioning and navigation?
    • The drone features Real-Time Kinematic (RTK) positioning technology, providing centimeter-level accuracy for precise navigation and stable flight, even in challenging environments.
  • What kind of flight modes does the DJI Agras T25 offer?
    • The Agras T25 offers intelligent flight modes such as automated flight planning, terrain-following, and contour-following. These modes allow the drone to adapt to various field conditions and execute streamlined operations.
  • How does the DJI Agras T25 ensure safety during its operation?
    • The drone is equipped with multiple safety features, including advanced obstacle avoidance sensors, emergency stop, and return-to-home functions. It also has redundant systems to enhance operational reliability.
  • Can the DJI Agras T25 operate in harsh weather conditions?
    • Yes, the Agras T25 is designed with a robust and weather-resistant construction, making it capable of operating in harsh agricultural environments while ensuring durability and longevity.
  • What are the maintenance requirements for the DJI Agras T25?
    • The Agras T25 features a modular design, making it easy to assemble, disassemble, and maintain. Its components are also designed for easy cleaning, ensuring quick repairs and minimizing downtime.
  • How efficient is the DJI Agras T25 in terms of area coverage?
    • The DJI Agras T25 can cover up to 25 acres per hour, significantly improving operational efficiency. Its high flight speed and optimized flight paths reduce the overall time required for spraying tasks.
  • What management tools are available for the DJI Agras T25?
    • The drone integrates with the DJI Agras Management Platform, offering tools for planning, monitoring, and analyzing flight data. It supports real-time data transmission and cloud storage for efficient fleet management.
  • What kind of agricultural tasks can the DJI Agras T25 perform?
    • The Agras T25 is versatile and can be used for spraying pesticides, herbicides, and fertilizers. It is suitable for various crop types and field sizes, enhancing its utility in diverse farming operations.
  • Is the DJI Agras T25 easy to operate for new users?
    • Yes, the Agras T25 comes with an intuitive remote controller featuring a high-resolution display and a user-friendly app that provides detailed guidance and real-time feedback, making it easy to operate even for beginners.
